VL Series

The VL-Series, based on Canadian Philips-Olympia technology, excels in rigidity, speed, precision, and cutting force. With a dynamic C-axis, second spindle for compound cutting, and various attachments like grinding, it delivers high-performance solutions for complex shapes.
Work Range X/Y/Z

1600 mm

Work Travel X/Y

-150/1100/1000 mm

Worktable Max Speed

250 rpm

Main Motor Power

37/45 kW

Spindle Torque

19578 N·m

Highlights

Spindle Servo Motor Drive

Variable-speed mechanical gear shifting enhances machine flexibility and torque. Helical belts ensure smooth, low-noise, and long-lasting operation.

High Rigidity Closed Frame

A large cross-section design ensures the machine’s structure remains highly rigid during heavy operations.

High Rigidity Beam Structure

Wide guideways with precision ball screw drives ensure transmission accuracy and stability. Four locking cylinders boost beam rigidity.

Saddle Guideways

Tin-bronze guideways and INA bearings ensure superior contact rigidity, axial support, and zero-backlash Z-axis transmission.

Forged Steel Ram

The double V-face tool post delivers 13 tons of clamping force, ensuring strong rigidity for high-precision turning.
